DRA1 Series | DC Output

DIN Rail Mount DC Output SSRs


  • /media/djcatalog2/images/item/13/dra1-series-dc-output.jpg

    Manufacturer: Sensata BEI Kimco

    DC output PCB mounted Single-in-Line Solid State Relays

      • Ratings from 3A to 10A and 1 VDC to 200 VDC
      • Single Channel Output
      • Transistor or FET output
      • LED input status indicator
      • DC control
    Services
    Professional and fast quote
    Product usually available on stock

    Delivery:

    • ASK for "Just in time" delivery

    More questions?

    +39 02 3340 0846 or Contact us

    Questions?

    +39 02 3340 0846
    or Contact us

    Description

    The DRA1 Series combine DC output PCB mounted Single-in-Line Solid State Relays with 10mm wide DIN rail mounted sockets to create ready-to-use assemblies, which are ideal for low to medium power control for heating, lighting or motion control applications.

    Main features of the DRA1 Series DC output assemblies are:

    • Ratings from 3A to 10A and 1 VDC to 200 VDC
    • Single Channel Output
    • Transistor or FET output
    • LED input status indicator
    • DC control
    Part Number Control Voltage Range Maximum Load Current Operating Voltage Range
    DRA1-CMX100D10 3-10 VDC 10 A 1-100 VDC
    DRA1-CMX100D6 3-10 VDC 6 A 1-100 VDC
    DRA1-CMX200D3 3-10 VDC 3 A 1-200 VDC
    DRA1-CMX60D10 3-10 VDC 10 A 1-60 VDC
    DRA1-CMX60D5 3-10 VDC 5 A 1-60 VDC
    DRA1-CMXE100D10 20-28 VDC 10 A 1-100 VDC
    DRA1-CMXE100D6 20-28 VDC 6 A 1-100 VDC
    DRA1-CMXE200D3 20-28 VDC 3 A 1-200 VDC
    DRA1-CMXE60D10 20-28 VDC 10 A 1-60 VDC
    DRA1-CMXE60D5 20-28 VDC 5 A 1-60 VDC
    DRA1-MPDCD3 3-32 VDC 3 A 3-60 VDC
    DRA1-MPDCD3-B 3-32 VDC 3 A 3-60 VDC
