Electrical Travel 50 to 965 mm
Resistance 80Ω/mm
Resistance Tolerance: +/-20%
Power Rating At 70°C 0.5 watts per 50mm of electrical travel (Derated to 0 watts at 125°C)
Output Smoothness 0.1% of total applied voltage
Insulation Resistance at 250VDC 50 megaohms min
Resolution Infinite
Accuracy Varies with length (.04% to 0.75%)
Dielectric 250VDC
Operating Temperature -40°C to +125°C (Available up to 200°C)
Actuation Force 0.56 Newtons max
Repeatability Within 0.013mm
