• Contact Arrangement —
  1 Form C (SPDT)
• Contact Material —
  Stationary —
  Gold/platinum/palladium/silver alloy
  (gold plated)
  Moveable —
  Gold/platinum/palladium/silver alloy
  (gold plated)
• Contact Resistance —
  Before Life — 100 milliohms max.
  (measured @ 10 mA @ 6 Vdc)
  After Life — 200 milliohms max.
  (measured @ 1 A @ 28 Vdc)
• Mechanical Life Expectancy —
  1 million operations
• Coil Voltage — 5 to 26.5 Vdc
• Coil Power — 512 mW max. @ 25°C
• Duty Cycle — Continuous
• Pick-up Voltage — Approximately
  50% of nominal coil voltage
• Pick-up Sensitivity —
  100 mW max. @ 25°C

For further technical details please refer to datasheet below.
