• Contact Arrangement —
  1 Form C (SPDT)
• Contact Material —
  Stationary — Hardened silver alloy
  Moveable — Hardened silver alloy
• Contact Resistance —
  Before Life — 50 Milliohms max.
  (measured at 10 mA @ 6 Vdc)
  After Life — 100 Milliohms max.
  (measured @ 1 A @28 Vdc)
• Contact Rating —
  Contact Load — 10 A 28 Vdc
  Type — Resistive
  Operations min. 50,000
• Mechanical Life Expectancy —
  1 million operations min.
• Coil Voltage — 6 to 26.5 Vdc
• Coil Power — 1.4 watts max. @ 25°C

For further technical details please refer to datasheet below.
